1 Key Laboratory for Liquid-Solid Structural Evolution and Processing of Materials (Ministry of Education), Shandong University, Jinan 250061, China 2 School of Materials Science and Engineering, Shandong University, Jinan 250061, China 3 Suzhou Institute, Shandong University, Suzhou 215123, Jiangsu, China
Based on the basic principle of biomineralization, hydroxyapatite fiber (HAF) with high crystallinity was fabricated via a hydrothermal route with Ca(NO3)2·4H2O and (NH4)2HPO4 as the resources, respectively. Effects of the addition of acidic amino acid L-glutamic acid (Glu), neutral amino acid L-phenylalanine (Phe) and basic amino acid L-lysine (Lys) on the phase composition and morphology of the obtained products were laid special emphasis on. The results show that the products obtained by using the three amino acids are all hydroxyapatite (HA) phase with minor CaCO3 in some samples. Meanwhile, all of the amino acids inhibit the growth of the fibers. Spherical morphology exists when Glu is added, the homogeneity of the fibers deteriorates with the addition of Lys. However, rod-like fibers with good uniformity can be obtained with the addition of Phe.
KOMLEV V S , BARINOV S M , KOPLIK E V . A method to fabricate porous spherical hydroxyapatite granules intended for time-controlled drug release[J]. Biomaterials, 2002, 23 (16): 3449- 3454.
2
SADAT-SHOJAI M , MOHAMMAD-TAGHI K , EHSAN DINPANAH-KHOSHDARGI , et al. Synthesis methods for nanosized hydroxyapatite with diverse structures[J]. Acta Biomaterialia, 2013, 9 (8): 7591- 7621.
3
QI M L , XIAO G Y , SHOKUHFAR T , et al. Flexible hydroxyapatite fiber precipitated by urea via hydrothemal route[J]. Surface Innovation, 2017,
doi: 10.1680/jsuin.16.00024
LONG J P , HAO X L , LIN J H . Preparation and characterization of fluoroapatite particles via microemulsion[J]. Journal of Materials Engineering, 2013, (7): 83- 86.
5
OTA Y , IWASHITA T , KASUGA T , et al. Novel preparation method of hydroxyapatite fibers[J]. Journal of the American Ceramic Society, 1998, 81 (6): 1665- 1668.
6
TAS A C . Molten salt synthesis of calcium hydroxyapatite whiskers[J]. Journal of the American Ceramic Society, 2001, 84 (2): 295- 300.
7
QI M L , XIAO G Y , LU Y D . Rapid hydrothermal synthesis of submillimeter ultralong flexible hydroxyapatite fiber using different pH regulators[J]. Acta Metallurgica Sinica (English Letters), 2016, 29 (7): 609- 613.
8
ZHANG Y G , ZHY Y J , CHEN F . Highly porous ceramics based on ultralong hydroxyapatite nanowires[J]. RSC Advances, 2016, 6 (104): 102003- 102009.
9
FRANCO P Q , JOÃO C F C , SILVA J C , et al. Electrospun hydroxyapatite fibers from a simple sol-gel system[J]. Materials Letters, 2012, 67 (1): 233- 236.
ZHONG W Z , LUO H , HUANG X W , et al. Crystallographic orientation and morphology of anion coordination phosphate crystals[J]. Journal of Inorganic Materials, 1999, 14 (2): 223- 227.
11
AN L , LI W , XU Y , et al. Controlled additive-free hydrothermal synthesis and characterization of uniform hydroxyapatite nanobelts[J]. Ceramics International, 2015, 42 (2): 3104- 3112.
12
YAN L , LI Y D , DENG Z X , et al. Surfactant-assisted hydrothermal synthesis of hydroxyapatite nanorods[J]. International Journal of Inorganic Materials, 2001, 3 (7): 633- 637.
13
WANG Y J , CHEN J D , WEI K , et al. Surfactant-assisted synthesis of hydroxyapatite particles[J]. Materials Letters, 2006, 60 (27): 3227- 3231.
14
NGA N K , GIANG L T , HUY T Q , et al. Surfactant-assisted size control of hydroxyapatite nanorods for bone tissue engineering[J]. Colloids and Surfaces B Biointerfaces, 2014, 116 (14): 666- 673.
15
高珊. 表面活性剂对羟基磷灰石纳米线合成的影响研究[D]. 山东: 山东大学, 2012.
15
GAO S. Study on the effect of surfactants on the synthesis of hydroxyapatite nanowire[D].Shandong:Shandong University, 2012.
16
张海斌. 羟基磷灰石晶粒/粒子的水热控制合成[D]. 长沙: 中南大学, 2011.
16
ZHANG H B.Study on controlled synthesis of hydroxyapatite crystal/particle under hydrothermal condition[D].Changsha:Central South University, 2011.
17
GAO W M , RUAN C X , CHEN Y F . Effects of acidic amino acids on hydroxyapatite morphology[J]. Key Engineering Materials, 2007, 336-338, 2096- 2099.
18
MATSUMOTOA T , OKAZAKIB M , INOUE M , et al. Crystallinity and solubility characteristics of hydroxyapatite adsorbed amino acid[J]. Biomaterials, 2002, 23 (10): 2241- 2247.
19
KOUTSOPOULOS S , DALAS E . Inhibition of hydroxyapatite formation in aqueous solutions by amino acids with hydrophobic side groups[J]. Langmuir, 2000, 16 (16): 6739- 6744.
20
KOUTSOPOULOS S , DALAS E . The effect of acidic amino acids on hydroxyapatite crystallization[J]. Journal of Crystal Growth, 2000, 217 (4): 410- 415.
21
SPANOS N , KLEPETANIS P G , KOUTSOUKOS P G . Model studies on the interaction of amino acids with biominerals: the effect of L-serine at the hydroxyapatite-water interface[J]. Journal of Colloid and Interface Science, 2001, 236 (2): 260- 265.
22
JACK K S , TIMOTHY G V , TRAU M . Characterization and surface properties of amino-acid-modified carbonate-containing hydroxyapatite particles[J]. Langmuir, 2007, 23 (24): 12233- 12242.
23
ROEDER K R , CONVERSE G L , LENG H , et al. Kinetic effects on hydroxyapatite whiskers synthesized by the chelate decomposition method[J]. Journal of the American Ceramic Society, 2006, 89 (7): 2096- 2104.
24
VISWANATH B , RAVISHANKAR N . Controlled synthesis of plate-shaped hydroxyapatite and implications for the morphology of the apatite phase in bone[J]. Biomaterials, 2008, 29 (36): 4855- 4863.
25
ZHANG H G , ZHU Q S , WANG Y . Morphologically controlled synthesis of hydroxyapatite with partial substitution of fluorine[J]. Chemistry of Materials, 2005, 17 (23): 5824- 5830.
QI M L , QI J , XIAO G Y , et al. Effect of surfactants on the morphology of hydroxyapatite fibers[J]. Journal of Inorganic Materials, 2016, 31 (7): 726- 730.
27
QI M L , QI J , XIAO G Y , et al. One-step hydrothermal synthesis of carbonated hydroxyapatite porous microspheres with a large and uniform size regulated by L-glutamic acid[J]. Crystengcomm, 2016, 18 (31): 5876- 5884.
28
BARTH A . The infrared absorption of amino acid side chains[J]. Progress in Biophysics and Molecular Biology, 2000, 74 (3): 141- 173.
29
PALAZZON B , WALSH D , LAFISCO M , et al. Amino acid synergetic effect on structure, morphology and surface properties of biomimetic apatite nanocrystals[J]. Acta Biomaterialia, 2009, 5 (4): 1241- 1252.
30
KOUTSOPOULOS S , DALAS E . The crystallization of hydro-xyapatite in the presence of lysine[J]. Journal of Colloid and Interface Science, 2000, 231 (2): 207- 212.
31
YANG X D , XIE B Q , WANG L J , et al. Influence of magnesium ions and amino acids on the nucleation and growth of hydroxyapatite[J]. Crystengcomm, 2011, 13 (4): 1153- 1158.
2017, Vol. 45
)
