In order to solve the problem that the Ni-P alloy coating with an amorphous structure having excellent corrosion resistance cannot be obtained in the conventional electrodeposition process, Ni-P alloy coatings were prepared on the basis of a high-speed electroplating bath, and the law of influence of waveform parameters on the amorphization process of Ni-P alloy coatings was studied by using Fei's square wave electrodeposition method. The micromorphologies of Ni-P alloy coatings were characterized by scanning electron microscopy (SEM) under different conditions. The P content of the coatings was analyzed by energy spectrum analysis (EDS). Structural changes of phase of the coatings were investigated by X-ray diffraction (XRD). The optimized pulse process parameters are: the average current density is 15 A/dm2, the inverse pulse coefficient is 0.3, the duty ratio is 0.6, and the frequency is 1 Hz. The results show that by adjusting Fei's square wave pulse parameters, the fully amorphous Ni-P alloy coating can be electrodeposited, which has the features of high P content up to 17.93% (mass fraction), negligible nickel crystal diffraction peaks, and the smooth surface with a bright appearance as well.
TALBOT D E J, TALBOT J D R.Corrosion science and technology[M].Boca Raton: CPC Press, 2007: 13-17.
2
BYK T V , GAEVSKAYA T V , TSYBULSKAYA L S . Effect of electrodeposition conditions on the composition, microstructure, and corrosion resistance of Zn-Ni alloy coatings[J]. Surface & Coatings Technology, 2008, 202 (24): 5817- 5823.
3
NARAYANAN T S N S , KRISHNAVENI K , SESHADRI S K . Electroless Ni-P/Ni-B duplex coatings: preparation and evaluation of microhardness, wear and corrosion resistance[J]. Materials Chemistry & Physics, 2003, 82 (3): 771- 779.
4
BERTERO E , HASEGAWA M , STAUBLI S , et al. Electrodeposition of amorphous Fe-Cr-Ni stainless steel alloy with high corrosion resistance, low cytotoxicity and soft magnetic properties[J]. Surface & Coatings Technology, 2018, 349, 745- 751.
5
CHOU M C , GER M D , KE S T , et al. The Ni-P-SiC composite produced by electro-codeposition[J]. Material Chemical Physical, 2005, 92 (1): 146- 151.
doi: 10.1016/j.matchemphys.2005.01.021
6
BEKISH Y N , POZNYAK S K , TSYBULSKAYA L S , et al. Electrodeposited Ni-B alloy coatings:structure, corrosion resistance and mechanical properties[J]. Electrochimica Acta, 2009, 55 (7): 2223- 2231.
7
HUANG H C , CHUNG S T , PAN S J , et al. Microstructure evolution and hardening mechanisms of Ni-P electrodeposits[J]. Surface & Coatings Technology, 2010, 205 (7): 2097- 2103.
8
LIU Y , SUN H . Study on the technology of Ni-P electroless plating on the Mg alloy[J]. Rare Metal Materials and Engineering, 2012, 41 (Suppl 1): 472- 474.
9
KRISHNAN K H , JOHN S , SRINIVASAN K N , et al. An overall aspect of electroless Ni-P depositions—a review article[J]. Metallurgical & Materials Transactions A, 2006, 37 (6): 1917- 1926.
10
BAHRAMIAN A , EYRAUD M , VACANDIO F , et al. Improving the corrosion properties of amorphous Ni-P thin films using different additives[J]. Surface & Coatings Technology, 2018, 345, 40- 52.
11
GULLA M, SHIPLEY C R, MACKAY H A.Electroless nickel plating: US4152164[P].1979-05-01.
12
RABIZADEH T , ALLAHKARAM S R , ZAREBIDAKI A . An investigation on effects of heat treatment on corrosion properties of Ni-P electroless nano-coatings[J]. Materials & Design, 2010, 31 (7): 3174- 3179.
13
LIN N M , ZHOU P , ZOU J , et al. Wear and corrosion resistance of electroless plating Ni-P coating on P110 steel[J]. Journal of Wuhan University of Technology (Materials Science Edition), 2015, 30 (3): 622- 625.
doi: 10.1007/s11595-015-1200-z
CHEN Y , FEI J Y , WANG L , et al. Preparation of high-P nickel-based alloy coatings by pulse electrodeposition[J]. Journal of Chinese Society for Corrosion and Protection, 2012, 32 (6): 501- 506.
15
BRENNER A , COUCH D E , WILLIAMS E K . Electrodeposition of alloys of phosphorus with nickel or cobalt[J]. Journal of Research of the National Bureau of Standards, 1950, 44 (1): 109.
doi: 10.6028/jres.044.009
16
XUE Y J , LIU H B , LAN M M , et al. Effect of different electrodeposition methods on oxidation resistance of Ni-CeO2, nanocomposite coating[J]. Surface & Coatings Technology, 2010, 204 (21/22): 3539- 3545.
17
FEI J Y , WILCOX G D . Electrodeposition of Zn-Co alloys with pulse containing reverse current[J]. Electrochimica Acta, 2005, 50 (13): 2693- 2698.
doi: 10.1016/j.electacta.2004.11.014
18
BAI A , CHUANG P Y , HU C C . The corrosion behavior of Ni-P deposits with high phosphorous contents in brine media[J]. Materials Chemistry & Physics, 2003, 82 (1): 93- 100.
PENG Q Y , FEI J Y , CHEN J T , et al. Fast electrodeposition of amorphous Ni-P/Al2O3composite coatings deposited by bi-directional pulse[J]. Journal of Materials Engineering, 2018, 46 (3): 81- 90.
20
XIA Z H , ZHANG M , ZHANG Y , et al. Effects of Ni-P amorphous films on mechanical and corrosion properties of Al0.3 Co-CrFeNi high-entropy alloys[J]. Intermetallics, 2018, 94, 65- 72.
doi: 10.1016/j.intermet.2017.12.021
21
REN L W , WANG Z , MENG M M , et al. Plasticity enhancement in bulk metallic glasses by electroless plating with Ni-P amorphous films[J]. Journal of Non-Crystalline Solids, 2015, 430, 115- 119.
doi: 10.1016/j.jnoncrysol.2015.10.008
2020, Vol. 48
), 张嫚, 韩锡正, 赵利娜
