Research progress in flexible resistive random access memory materials
Da-xiu TANG1,2,3, Jin-yun LIU2,3, Yu-xin WANG1,2,3, Jie SHANG2,3,*(), Gang LIU2,3, Yi-wei LIU2,3, Hui ZHANG1, Qing-ming CHEN1, Xiang LIU1,*(), Run-wei LI2,3,*()
1 School of Materials Science and Engineering, Kunming University of Science and Technology, Kunming 650093, China 2 CAS Key Laboratory of Magnetic Materials and Devices, Ningbo Institute of Materials Technology and Engineering, Chinese Academy of Sciences, Ningbo 315201, China 3 Zhejiang Province Key Laboratory of Magnetic Materials and Application Technology, Ningbo Institute of Materials Technology and Engineering, Chinese Academy of Sciences, Ningbo 315201, China
The basic structure, working principle, and the development process and research status of resistive random access memory (RRAM) were outlined. Material systems, including dielectric materials, electrode materials, and substrate materials, as well as broad trends and recent researches of flexible RRAM were summarized; the performance characteristics of flexible RRAM, including storage performance and mechanics performance, were analyzed. The significance and challenge of developing flexible RRAM were explicated. Problems existing in this area and possible approaches to the problems were also put forward. It was concluded that the highly conductive stretchable electrode and the steadily stored stretchable dielectric are primary direction in the future.
