1 Shanghai Spaceflight Precision Machinery Institute, Shanghai 201600, China 2 School of Chemistry and Chemical Engineering, Huazhong University of Science and Technology, Wuhan 430074, China 3 Management Committee of Ningdong Energy Chemical Industry Base, Yinchuan 750411, China
The traditional preparation process of superhydrophobic surfaces(SHS) is complicated and the mechanical stability of SHS is less than satisfactory in most cases, which seriously restricts the practical application. The "binder+nanoparticles" strategy was used to prepare a nonfluorinated, durable and stable superhydrophobic epoxy composite coating on magnesium alloy. The contact angle test results show that the maximum contact angle of the composite coating is 160.2°, and the contact angle is still as high as 103° even after 30 days of soaking in 3.5%(mass fraction) NaCl solution; EIS results indicate that the |Z|0.01 Hz of the composite coating is still above 109 Ω·cm2 even after five accelerated aging cycles, demonstrating excellent resistance to salt fog and anticorrosion performance; Friction and wear test results reveal that the |Z|0.01 Hz of the composite coating is as high as 1.84×109 Ω·cm2 after mechanical friction under 19.6 N load for 8 h. Due to the excellent blocking barrier of "air cushion", the composite coating can provide efficient and durable corrosion protection for magnesium alloy and the "adhesive+nanoparticles" strategy provides a new direction for the preparation of superhydrophobic coating.
WU G H , CHEN Y S , DING W J . Current research, application and future prospect of magnesium alloys in aerospace industry[J]. Manned Spaceflight, 2016, 22 (3): 281- 292.
doi: 10.3969/j.issn.1674-5825.2016.03.002
3
XIAO L , DENG M , ZENG W G , et al. Novel robust superhydrophobic coating with self-cleaning properties in air and oil based on rare earth metal oxide[J]. Industrial & Engineering Chemistry Research, 2017, 56 (43): 12354- 12361.
4
FURSTNER R , BARTHLOTT W , NEINHUIS C , et al. Wetting and self-cleaning properties of artificial superhydrophobic surfaces[J]. Langmuir, 2005, 21 (3): 956- 961.
doi: 10.1021/la0401011
HE Z W , SHEN Z H , QIU H Y , et al. Research progress in aluminum-based anti-icing surfaces[J]. Journal of Materials Engineering, 2021, 49 (9): 41- 50.
6
SHEN Y , WU Y , TAO J , et al. Spraying fabrication of durable and transparent coatings for anti-icing application: dynamic water repellency, icing delay, and ice adhesion[J]. ACS Applied Materials & Interfaces, 2018, 11 (3): 3590- 3598.
7
ZULFIQAR U , HUSSAIN S Z , SUBHANI T , et al. Mechanically robust superhydrophobic coating from sawdust particles and carbon soot for oil/water separation[J]. Colloids and Surfaces A, 2018, 539, 391- 398.
doi: 10.1016/j.colsurfa.2017.12.047
8
VAZIRINASAB E , JAFARI R , MOMEN G . Application of superhydrophobic coatings as a corrosion barrier: a review[J]. Surface and Coatings Technology, 2018, 341, 40- 56.
doi: 10.1016/j.surfcoat.2017.11.053
9
DAS S , KUMAR S , SAMAL S K , et al. A review on superhydrophobic polymer nanocoatings: recent development and applications[J]. Industrial & Engineering Chemistry Research, 2018, 57 (8): 2727- 2745.
10
LIU K , ZHANG M , ZHAI J , et al. Bioinspired construction of Mg-Li alloys surfaces with stable superhydrophobicity and improved corrosion resistance[J]. Applied Physics Letters, 2008, 92 (18): 183103- 183106.
doi: 10.1063/1.2917463
ZHU Y L , FAN W B , FENG L B , et al. Anti-adhesion and corrosion resistance of superhydrophobic magnesium alloy surface[J]. Journal of Materials Engineering, 2016, 44 (1): 66- 70.
12
KOBINA S E , KOBINA S D , LV X , et al. Recent development in the fabrication of self-healing superhydrophobic surfaces[J]. Chemical Engineering Journal, 2019, 373, 531- 546.
doi: 10.1016/j.cej.2019.05.077
13
GUO C , FENG L , ZHAI J , et al. Large-area fabrication of a nanostructure-induced hydrophobic surface from a hydrophilic polymer[J]. ChemPhysChem, 2004, 5 (5): 750- 753.
doi: 10.1002/cphc.200400013
14
ZHAI L , CEBECI F C , COHEN R E , et al. Stable superhydrophobic coatings from polyelectrolyte multilayers[J]. Nano Letters, 2004, 4 (7): 1349- 1353.
doi: 10.1021/nl049463j
15
QIAN B , SHEN Z . Fabrication of superhydrophobic surfaces by dislocation-selective chemical etching on aluminum, copper, and zinc substrates[J]. Langmuir, 2005, 21 (20): 9007- 9009.
doi: 10.1021/la051308c
16
XU W , SONG J , SUN J , et al. Rapid fabrication of large-area, corrosion-resistant superhydrophobic Mg alloy surfaces[J]. ACS Applied Materials & Interfaces, 2011, 3 (11): 4404- 4414.
17
LAU K K , BICO J , TEO K B , et al. Superhydrophobic carbon nanotube forests[J]. Nano Letters, 2003, 3 (12): 1701- 1705.
doi: 10.1021/nl034704t
18
王帅. 静电纺丝法制备功能性超疏水材料[D]. 长春: 吉林大学, 2013.
18
WANG S. Preparation of functional superhydrophobic materials by electrospinning[D]. Changchun: Jilin University, 2013.
19
JOUNG Y S , BUIE C R . Electrophoretic deposition of unstable colloidal suspensions for superhydrophobic surfaces[J]. Langmuir, 2011, 27 (7): 4156- 4163.
doi: 10.1021/la200286t
20
LI Y , LI B , ZHAO X , et al. Totally waterborne, nonfluorinated, mechanically robust and self-healing superhydrophobic coatings for actual anti-icing[J]. ACS Applied Materials & Interfaces, 2018, 10 (45): 39391- 39399.
21
WANG D , SUN Q , HOKKANEN M J , et al. Design of robust superhydrophobic surfaces[J]. Nature, 2020, 582 (7810): 55- 59.
doi: 10.1038/s41586-020-2331-8
22
LI C , LAI H , CHENG Z , et al. Coating "nano-armor" for robust superwetting micro/nanostructure[J]. Chemical Engineering Journal, 2020, 385, 123924- 123933.
doi: 10.1016/j.cej.2019.123924
23
WANG Y , LIU Y , LI J , et al. Fast self-healing superhydrophobic surfaces enabled by biomimetic wax regeneration[J]. Chemical Engineering Journal, 2020, 390, 124311- 124317.
doi: 10.1016/j.cej.2020.124311
24
XIA X C , CAO X K , CAI G Y , et al. Underwater superoleophobic composite coating characteristic of durable antifouling and anticorrosion properties in marine environment[J]. Colloids and Surfaces A, 2021, 628, 127323- 127336.
doi: 10.1016/j.colsurfa.2021.127323
LI W M , PENG C Y , YANG J S , et al. Preparation of all-organic superhydrophobic PTFE/epoxy composite coatings[J]. Journal of Materials Engineering, 2020, 48 (7): 162- 169.
26
RAO A V , LATTHE S S , MAHADIK S A , et al. Mechanically stable and corrosion resistant superhydrophobic sol-gel coatings on copper substrate[J]. Applied Surface Science, 2011, 257 (13): 5772- 5776.
doi: 10.1016/j.apsusc.2011.01.099
27
GUO F , WEN Q , PENG Y , et al. Multifunctional hollow superhydrophobic SiO2 microspheres with robust and self-cleaning and separation of oil/water emulsions properties[J]. Journal of Colloid and Interface Science, 2017, 494, 54- 63.
doi: 10.1016/j.jcis.2017.01.070
28
JIANG D , XIA X , HOU J , et al. Enhanced corrosion barrier of microarc-oxidized Mg alloy by self-healing superhydrophobic silica coating[J]. Industrial & Engineering Chemistry Research, 2018, 58 (1): 165- 178.
2022, Vol. 50
), 聂敬敬1, 庞松1, 袁勇1, 董泽华2,*(
