1 State Key Laboratory of Powder Metallurgy, Central South University, Changsha 410083, China 2 Science and Technology of Advanced Functional Composites Laboratory, Aerospace Research Institute of Materials and Processing Technology, Beijing 100076, China
One-staged forming of porous C/C composites as well as volume fraction control of pores were realized, based on thermophysical property analysis and proportioning design of raw materials. Short fiber reinforced C/C-SiC composites with high densification and low content of residual Si were prepared by hot-pressing-infiltration two-step method at low temperature. The structural evolution of C/C-SiC composites was analyzed in detail, the mechanical properties as well as failure behaviors were also investigated. Results show that the porous C/C composites present bipolar distribution in pore size, adding aramid fibers is an effective method to improve the connectivity of network pores, exhibiting a significant regulatory effect. Both SiC network skeleton and pinning structure with strong interface between SiC matrix and carbon fiber bundle can entrust the excellent mechanical properties of C/C-SiC composites with high carbon fiber content. In addition, the fracture toughness of C/C-SiC composites can be improved significantly with the addition of aramid fibers, resulting in the increase of crack propagation path. The isotropic distribution of carbon fiber in plane and the uniform distribution of ceramic phase between layers play a positive role in improving the bearing capacity and friction stability of C/C-SiC composites.
KRENKEL W. C/C-SiC composites for hot structures and advanced friction systems[C]//KRIVEN W M, LIN H T. 27th International Cocoa Beach Conference on Advanced Ceramics and Composites: B. Westerville, USA: AMER CERAMIC SOC, 2003: 583-592.
3
HEIDENREICH B , BAMSEY N , SHI Y , et al. Manufacture and test of C/C-SiC sandwich structures[J]. Ceas Space Journal, 2020, 12 (1): 73- 84.
doi: 10.1007/s12567-019-00263-x
4
PATEL M , SAURABH K , PRASAD V V B , et al. High temperature C/C-SiC composite by liquid silicon infiltration: a literature review[J]. Bulletin of Materials Science, 2012, 35 (1): 63- 73.
doi: 10.1007/s12034-011-0247-5
5
LI F , XIAO P , LI Z , et al. Microstructures and properties of C/C-SiC composites derived from different gaseous carbon matrix precursors[J]. Ceramics International, 2021, 47 (21): 30777- 30789.
doi: 10.1016/j.ceramint.2021.07.258
6
WANG J , PEI X , ZHI J , et al. The effects of phenolic resin-derived PyC interlayers on microstructure and mechanical properties of Cf/SiC composites[J]. Ceramics International, 2018, 44 (14): 16157- 16163.
doi: 10.1016/j.ceramint.2018.05.076
7
KRNEL K , STADLER Z , KOSMAC T . Carbon/carbon-silicon-carbide dual-matrix composites for brake discs[J]. Materials and Manufacturing Processes, 2008, 23 (6): 587- 590.
doi: 10.1080/10426910802160437
8
KRENKEL W, LANGHOF N. Ceramic matrix composites for high performance friction applications[C]//Proceedings of the Ⅳ Advanced Ceramics and Applications Conference. Paris: Atlantis Press, 2017: 13-28.
SUN G S , LIU R J , CAO Y B , et al. Research progress of C/C-SiC composite for brake[J]. Materials Review, 2016, 30 (Suppl 1): 516- 519.
10
XI O Y , LI Z , XIAO P , et al. Effects of the high-temperature treatment of C/C composites on their tribological properties[J]. New Carbon Materials, 2019, 34 (5): 472- 480.
doi: 10.1016/S1872-5805(19)60025-9
11
JIANG G , YANG J , XU Y , et al. Effect of graphitization on microstructure and tribological properties of C/SiC composites prepared by reactive melt infiltration[J]. Composites Science and Technology, 2008, 68 (12): 2468- 2473.
doi: 10.1016/j.compscitech.2008.04.025
XIAO P , LI Z , XIONG X . C/C-SiC composites for advanced friction systems[J]. Journal of Materials Engineering, 2009, (Suppl 2): 263- 267.
13
RENZ R , SEIFERT G , KRENKEL W . Integration of CMC brake disks in automotive brake systems[J]. International Journal of Applied Ceramic Technology, 2012, 9 (4): 712- 724.
doi: 10.1111/j.1744-7402.2012.02812.x
14
MA X , FAN S , SUN H , et al. Investigation on braking performance and wear mechanism of full-carbon/ceramic braking pairs[J]. Tribology International, 2020, 142, 105981.
doi: 10.1016/j.triboint.2019.105981
15
DAI J , ZHANG Z , ZU Y , et al. Role of fiber-matrix adhesion at CFRP stage on microstructure and mechanical properties of C/C-SiC composite[J]. International Journal of Applied Ceramic Technology, 2021, 19 (1): 79- 90.
16
XU J , GUO L , WANG H , et al. Mechanical property and toughening mechanism of 2.5D C/C-SiC composites with high textured pyrocarbon interface[J]. Ceramics International, 2021, 47 (20): 29183- 29190.
doi: 10.1016/j.ceramint.2021.07.081
LI J W , XIAO P , LI Z , et al. Effect of short carbon fiber content on mechanical properties of C/C-SiC composites prepared by WP-LSI[J]. Materials Science and Engineering of Powder Metallurgy, 2014, 19 (5): 825- 831.
doi: 10.3969/j.issn.1673-0224.2014.05.025
MA Y , CHEN Z H . Effect of 1800℃ annealing on microstructures and properties of C/SiC composites fabricaed by precuesor infiltration and pyrolysis[J]. Journal of Materials Engineering, 2015, 43 (4): 98- 101.
DU P C , WANG Y L , XIONG X , et al. Mechanical and thermal diffusion properties of C/C-SiC composites with full-length fiber needled preform[J]. Mining and Metallurgical Engineering, 2021, 41 (3): 114- 119.
doi: 10.3969/j.issn.0253-6099.2021.03.028
CHEN L D , TONG X Y , YAO L J , et al. Influence of open hole on the mechanical behavior of plain-woven C/SiC ceramic matrix composites[J]. Journal of Materials Engineering, 2009, (9): 71- 74.
doi: 10.3969/j.issn.1001-4381.2009.09.017
LI Z , XIAO P , YUE J , et al. Wet friction and wear properties of C/C-SiC composites during different braking speeds[J]. Journal of Materials Engineering, 2013, (3): 71- 76.
doi: 10.3969/j.issn.1001-4381.2013.03.014
22
HEIDENREICH B , KRAFT H , BAMSEY N , et al. Shear properties of C/C-SiC sandwich structures[J]. International Journal of Applied Ceramic Technology, 2022, 19 (1): 54- 61.
doi: 10.1111/ijac.13818
ZHAO Y W , SUN W T , LI J P , et al. Preparation and microstructure of C/C-SiC composites by reaction melt infiltration[J]. Aerospace Materials and Technology, 2013, 43 (2): 64- 69.
doi: 10.3969/j.issn.1007-2330.2013.02.015
24
YANG J , AI Y , LV X , et al. Fabrication of C/C-SiC composites using high-char-yield resin[J]. International Journal of Applied Ceramic Technology, 2020, 18 (2): 449- 456.
25
GOO B C . Development and characterization of C/C-SiC brake disc[J]. Materials and Manufacturing Processes, 2016, 31 (8): 979- 988.
doi: 10.1080/10426914.2015.1019112
26
李专. C/C-SiC摩擦材料的制备、结构和性能[D]. 长沙: 中南大学, 2010.
26
LI Z. Preparation, microstructure and properties of C/C-SiC braking composite[D]. Changsha: Central South University, 2010.
ZHANG H L , DUAN M , LI S Z , et al. Fabication of C/C-SiC composites via catalytic carbonization-in situ reaction and catalytic carbonization-reactive melt infiltration process[J]. Journal of Materials Engineering, 2021, 49 (7): 85- 91.
28
TZENG S S , CHR Y G . Evolution of microstructure and properties of phenolic resin-based carbon/carbon composites during pyrolysis[J]. Materials Chemistry and Physics, 2002, 73 (2/3): 162- 169.
29
JAIN N , KOSIN M , SHI Y , et al. Characterization and modeling of transverse micro-cracking during pyrolysis process of carbon fiber reinforced plastics[J]. International Journal of Applied Ceramic Technology, 2019, 16 (5): 1734- 1743.
WANG L L , MA W M , JI A L , et al. Effect of C/C porous perform on the preparation and properties of C/C-SiC composites[J]. Journal of Materials Engineering, 2014, (7): 34- 38.
31
SRIVASTAVA V K , KRENKEL W , D'SOUZA V J A , et al. Manufacturing, analysis and modelling of porous Si-SiC ceramics derived by oxidation from C/C-Si-SiC composites[J]. Journal of Ceramic Science and Technology, 2011, 2 (2): 111- 118.
32
ZHANG Y , XU Y , GAO L , et al. Preparation and microstructural evolution of carbon/carbon composites[J]. Materials Science and Engineering: A, 2006, 430 (1/2): 9- 14.
WANG X J , LI Y , LIANG H , et al. Study on curing process of thermosetting phenolic resin based on in-situ infrared spectroscopy[J]. Aerospace Materials and Technology, 2018, 48 (6): 72- 77.
TIAN Z H , ZHANG X H , MEI M H . Principle and method of refractory pore structure measurement by mercury intrusion method[J]. Physical Testing and Chemical Analysis (Part A), 2013, 49 (9): 615- 617.
LI T , LI M , ZHANG L H , et al. Study on the relationship of tortuosity with por structure in micro-porous media[J]. Natural Gas Geoscience, 2018, 29 (8): 1181- 1189.
DING X X , ZHAN L H , LI S J , et al. Experimental study on high pressure microwave curing process of advanced resin matrix composites[J]. Fiber Reinforced Plastics/Composites, 2018, (1): 68- 72.
